Face Recognition Fingerprint Airport Turnstile

Product Introduction



Face recognition fingerprint airport turnstile CPW-143Y, integrated with QR code recognition, face recognition, passport / ID card recognition, and other multiple recognition methods, does real-name verification for pedestrians. Verification is accurate and fast with strong anti-tailgating ability. The side adopts tempered glass, transparent, bright.



It is suitable for airports, gateways, high-speed railway stations and other occasions with strict verification.



Advantages



Unique Feature of Face Recognition Fingerprint Airport Turnstile

Two gates are interlocked. When A/B gates are opened, B/A gates are closed. Pedestrian is allowed to access after passing the verification of two gates, so the security level is very high.



Strong mechanism structure: The lossless modular mechanism structure independently developed by CMOLO and the full CNC processing technology ensure the precision, strength, concentricity of the mechanism, and the transmission ratio are accurate, efficient and stable, which can precisely control the rotation angle of the gate and reduce the loss to ensure the reliability of the mechanism, and enhance the service life of the mechanism.



Core logic algorithm: Adopted CMOLO® patented passing detection algorithm and matrix photoelectric stereo detection technology, which can sensitively detect illegal intrusions such as reverse passing and tailgating, the face recognition fingerprint airport turnstile can issue warnings in the form of sound and light, and can be linked with other security systems. The face recognition fingerprint airport turnstile adopts advanced servo control system and DSP+ARM motor control technology, combined with CMOLO's original motor control algorithm, to achieve precise control and positioning of the obstacle and maintain stable performance.



Long service life: The mechanism and control system of the face recognition fingerprint airport turnstile have passed 10 million life tests.



Features



Interlocking double gate, anti-tailgating	Modular design, easy maintenance	Optimize the mechanism structure, high stability	Accurate & fast detection
Long life, longer than 10 million times	High compatibility, high integration	High safety, triple anti-pinch	High visitor flow rate usage
Advanced core patented technology



Dimension Drawing





Parameter



Technical Parameters
Operation temperature	﹣20℃~60℃
Normal throughput capacity	30 ~ 45 people / min(according to the condition of pedestrians)
Evacuation throughput capacity	60 people/min(according to the condition of pedestrians)
Opening speed	0.3-0.6s
Electric Parameters
Positioning Method	Use the encoder to position the wing gate accurately
Power supply	100-240VAC,50/60Hz
Rated power	100W
Input/ Output signal	12-channel relay signal output / 8-channel dry contact signal input
Communication interface	RS485 / RS232;TCP/IP interface(customizable)
Method of motor control	Use high-performance DSP chip
Driving motor	DC brushless motor



Application



Face recognition fingerprint airport turnstile CPW-143Y, is suitable for commercial buildings, airports, exhibition halls, government buildings, financial institutions, clubs and other high-end indoor applications.



FAQ



Q1: Does your company have experience in making airport turnstiles?

Answer: Yes, sure, we have rich experience in making airport turnstiles around the world.



Q2: Can you customize the cabinet of airport turnstile according to customer's specific requirements?

Answer: Sure, we can. Customization is CMOLO's main advantage. All our airport turnstiles cases are well customized to match to different airport's style and requirements.
