Tripod Turnstile with Card Reader

Advanced core patented technology

Optimize the mechanism structure, high stability

Long life, longer than 10 million times

Accurate & fast detection

IP65

High temperature resistance

Low temperature resistance

Condensation resistance

Modular design, easy maintenance

High compatibility, high integration

Type

Fully-auto tripod turnstile

Semi-auto tripod turnstile

Strong mechanism structure

The lossless modular mechanism structure independently developed by CMOLO adopts CNC machining technology to ensure the high precision of each module of the mechanism.

The mechanism adopts the mechanical structure of secondary transmission. The gear transmission ratio is precise, efficient and stable, which can precisely control the rotation angle of the arm and reduce the loss, ensure the reliability of the mechanism and enhance the service life of the mechanism.

The mechanism adopts advanced hydraulic buffer, with advanced buffer design structure, which effectively reduces the noise and mechanical vibration, makes the operation more efficient and stable, and reduces the loss, ensures the reliability of the mechanism and enhances the service life of the mechanism.

Core control algorithm

Using advanced servo control system and DSP+ARM motor control technology, combined with the motor control algorithm independently developed by CMOLO, to achieve precise control and positioning of the obstacle.

The main control center adopts the advanced algorithm based on ARM core, with advanced photoelectric sensors and high-quality solenoids, to achieve efficient and accurate control logic.

Arms status monitoring

The tripod turnstile adopts a closed-loop feedback control system to monitor the movement status of the arm, which can sensitively detect behaviors that threaten the safety of the passageway, such as illegally hitting the arm and reverse passage, and then issue warnings in the form of sound and light, and can be linked with other security systems.

-

Passing prompt of Automatic rotation

After the pedestrian provides a legal door opening signal, the arm rotates at a certain angle in the opening direction, indicating that the pedestrian can pass, and then the pedestrian gently pushes the arm, and the arm automatically rotates in the opening direction.

-

Over-force feedback control

When the gate is momentarily subjected to an impact force beyond the safe range, the gate can be slowly pushed for a certain distance to buffer the impact force on the mechanism and the reverse impact force on pedestrians.

-

Prevent reverse passage

Mechanical electric control locking structure design, anti-illegal hitting arm and reverse passage.

Mechanical electric control locking structure design, anti-illegal hitting arm and reverse passage.

Anti-tailgating

The tripod turnstile adopts mechanical anti-tailgating design, which can realize only one person passing through at a time.

Long service life

CMOLO's independently developed advanced mechanism structure, equipped with high-quality DC brushless motor (core of the mechanism), so that the mechanism has a long service life. The mechanism and control system of the tripod turnstile have passed 10 million life tests.

CMOLO's independently developed advanced mechanism structure, equipped with high-quality solenoid (core of the mechanism), so that the mechanism has a long service life. The mechanism and control system of the tripod turnstile have passed 10 million times life tests.

Appearance

Cabinet size, material and surface treatment process etc. of tripod turnstile with card reader can be moderately customized.

System integration

Integrate with access control system, human body temperature measurement system, ticketing system, time attendance system, visitor system etc.

Integrate with QR code, face, fingerprint, ID/IC card, passport identification system etc.

Integrate with card collection system, and customize card collection device
